WAI-ARIA: Role=Row

A row of cells in a tabular container.

Description

A row of cells in a tabular container.

Rows contain cell or gridcell elements, and thus serve to organize the table or grid.

In a treegrid, authors MAY mark rows as expandable, using the aria-expanded attribute to indicate the present status. This is not the case for an ordinary table or grid, in which the aria-expanded attribute is not present.

Authors MUST ensure elements with role row are contained in, or owned by, an element with the role table, grid, rowgroup, or treegrid.

Role=Row Example

HTML Example

The following example shows a grid with 16 columns, of which columns 2, 3, 4, and 9 are displayed to the user. Because the set of columns is non-contiguous, aria-colindex needs to be placed on all of the owned elements of each row.

<div role="grid" aria-colcount="16">
<div role="rowgroup">
<div role="row">
<span role="columnheader" aria-colindex="2">First Name</span>
<span role="columnheader" aria-colindex="3">Last Name</span>
<span role="columnheader" aria-colindex="4">Company</span>
<span role="columnheader" aria-colindex="9">Phone</span>
</div>
</div>
<div role="rowgroup">
<div role="row">
<span role="gridcell" aria-colindex="2">Fred</span>
<span role="gridcell" aria-colindex="3">Jackson</span>
<span role="gridcell" aria-colindex="4">Acme, Inc.</span>
<span role="gridcell" aria-colindex="9">555-1234</span>
</div>
<div role="row">
<span role="gridcell" aria-colindex="2">Sara</span>
<span role="gridcell" aria-colindex="3">James</span>
<span role="gridcell" aria-colindex="4">Acme, Inc.</span>
<span role="gridcell" aria-colindex="9">555-1235</span>
</div>
…
</div>
</div>

Characteristics

Superclass Role

• group
• widget

Base Concept

• HTML tr

Required Context Role

• grid
• rowgroup
• table
• treegrid

Required Owned Elements

• cell
• columnheader
• gridcell
• rowheader

Supported States and Properties

• aria-colindex
• aria-level
• aria-rowindex
• aria-selected

Inherited States and Properties

• aria-activedescendant
• aria-atomic
• aria-busy (state)
• aria-controls
• aria-current (state)
• aria-describedby
• aria-details
• aria-disabled (state)
• aria-dropeffect
• aria-errormessage
• aria-expanded (state)
• aria-flowto
• aria-grabbed (state)
• aria-haspopup
• aria-hidden (state)
• aria-invalid (state)
• aria-keyshortcuts
• aria-label
• aria-labelledby
• aria-live
• aria-owns
• aria-relevant
• aria-roledescription

Name From

• contents
• author

Semantic HTML

Use the HTML <tr> tag.

<table>
<tr>
<th>Month</th>
<th>Savings</th>
</tr>
<tr>
<td>January</td>
<td>$100</td>
</tr>
</table>

Reference

• W3C (opens new window)
